SPR-270 Oil mist filter
SPR-270 Oil mist filter
The SPR-270 filter is designed to purify air from fogs of cooling emulsions and oils formed during operation on various CNC machine tools and machining centers: turning, milling, drilling, threading, as well as other industrial equipment that operates using coolants and oils .
Scheme
| № | Name | Amount |
| 1 | Cover | 1 pc |
| 2 | Case | 1 pc |
| 3 | Base | 1 pc |
| 4 | Drainage tube | 1 pc |
| 5 | Suction pipe | 1 pc |
| 6 | Fixing points for size □ 177 mm | 4 pc |
- Power supply: standard single-phase 230 V, 50 Hz or three-phase 230/400 V, 50 Hz.
- The power of the electric motor is 0.274 kW.
- Overall dimensions (length x width x height), mm 412x412x388.
- Weight – 25 kg.
- The fan speed on the electric motor is 2500 rpm.
- The maximum productivity is 455 l / s.
- The maximum pressure is 714 Pa.
- Maximum temperature of filtered mist (air) 50 °
Principle of operation.
Contaminated air is sucked through the intake pipe into the lower chamber, where the liquid drops are circulated through the labyrinth system. Here,takes place the main cleaning of the air from oil vapors and emulsions. Then the air passes into the upper chamber and passes through another filter element and returns to the working room. The collected liquid flows back to the machine through the drainage tube.
